3s lithium ion battery pack LG 18650 cell 12v for led light

Novoxy 12v lithium ion battery pack is built with LG cell 18650 F1L

  • Nominal Voltage: 11.1V
  • Nominal Capacity: 20
  • Usable Capacity: 222Wh
Send message to us


Novoxy 12V led light  battery  is made with high quality 18650 li-ion cells ,which is UL,CB,UN38.3 and MSDS certificated. All battery pack will be tested with one cycle of discharging and charging before shipping.


Product Model NOV-1120
Items Basic Parameters
Configuration 3S6P -18650 3350mah
Norminal Nominal Voltage 11.1V
Nominal Capacity 20Ah
Usable Capacity 222Wh
Physical Dimension D 58 mm* H 205mm
Weight 0.9KGs
Electrical Operating Voltage Range 9V ~ 12.6V
Standard Charging Current 4A
Standard Discharging Current 20A
Max Charging Current 20A
Max Discharging Current 40A
Peak Discharging Current 50A(1S)
Others Charging Temperature 0 ~ 45 ℃
Discharging Temperature -20 ~ 55 ℃
Design Life 3+ year 25 ℃
Cycle Life > 1000

Details & applications


Grade A

Grade A li-ion cells

1000 cycles

Long cycle life up to 1000 cycles at 80%DOD.


PCM&BMS use the lastest American or Japanese chips.

High Standard

Superb assembly process, high standard test technology, high performance safety.

Environmental Protection

No toxic, no air pollution, good for evironmental protection.


Free maintenance, easy for installation, plug&play.

Reasonable Price

Factory wholesale price&Long time warranty.
