20S 60V 120Ah lithium battery for mobility scooter low speed car

Support big current for climbing hills (200A/250A/300A)
GPS positioning BT monitoring/Display screent optional
Grade A famous LiFePO4 parismatic cells Low temperature heated system
Long cycle life, high security
Self design, OEM/ODM service

Send message to us

Features

1.Drop-in replacement for lead acid batteries
2.Maintenance-free, modular, and lightweight
3.Holds a charge for up to 1 year without a load, and no need for a trickle charger - great for unattended storage
4.Can be wired in series up to 48V and unlimited in parallel
5.Built-in Battery Management System (BMS) protects the cells against excessively high or low voltages, high currents, short
circuits, and excessive heat or cold
6.Protections: high/low voltage; short circuit; high/low temperature

Specifications

Model Number NOV60120E
Nominal Voltage 74V
Nominal Capacity 120ah
Charge End-off Voltage 84V
Discharge End-off Voltage 60V
Charging Method CC-CV
Initial Charging Current Standard Charge   0.2C
Max. Charge  >10℃ 1.0C
0~10℃ 0.2C
Max continious discharge current  100Amps(can be customised)
peak discharge current    300Amps
Main Protection Function Over Charge, Over Discharge, Over current, Short Circuit
Operating temperature charge 0-60℃
discharge -20-60℃
Storage temperature  1 month:-20-45°C
3 months:-20-35°C
6 months: -20-25°C

Details & applications

Advantage

Grade A

Grade A LiFePO4 cells

6000 cycles

Long cycle life up to 6000 cycles at 80%DOD.

chips

PCM&BMS use the lastest American or Japanese chips.

High Standard

Superb assembly process, high standard test technology, high performance safety.

Environmental Protection

No toxic, no air pollution, good for evironmental protection.

Convenient

Free maintenance, easy for installation, plug&play.

Reasonable Price

Factory wholesale price&Long time warranty.
